New Energy Resources and Energy Storage
YUAN Wei, HAN Ruiyuan, DU Shuangqing, YANG Xianliang
To study the impact of spiral fins and circular fins on the heat transfer performance of the vertical tube-and-shell phase change energy storage tanks, the fin structure with better heat transfer performance was selected, and physical models of tube-and-shell phase change energy storage tanks with plain tubes, circular fins, and spiral fins were established. Considering natural convection, numerical simulations were conducted for the charging and discharging processes. The temporal variations of temperature field of the phase change materials, solid-liquid interface, average temperature, liquid phase mass fraction, and the temperatures at different monitoring points in various storage tanks were analyzed. The overall thermal performance of different storage tanks was discussed, and the main factors affecting the charging and discharging rate of the storage tanks were compared and analyzed. Results show that the presence or absence of fins has a significant impact on phase change materials with low thermal conductivity. The fin structure can significantly reduce the melting and solidification time of the phase change materials in the energy storage tanks during the heat transfer process. Radially extended circular fins restrict natural convection, while spiral fins, with their continuous structure, exhibit the best heat transfer rate among the three structures, and the heat transfer effect improves with increasing fin height. During the charging process, in the vertical direction, the upper part of the energy storage tank has a higher temperature, and the phase change materials melt first. In the radial direction, the phase change materials near the inner tube melt faster. The opposite occurs during the discharging process, where the phase change materials at the lower part in the vertical direction and the inner side in the radial direction solidify first.
